OEM Blood Test Tube Disposable Medical Syringe Barrel Plunger Mold with Multiple Cavities Hot Runner

Basic Info

Runner	Hot Runner
Design Software	UG
Installation	Fixed
Standard	HASCO
Customized	Customized
Product	Medical Products
Mould Surface Treatment	Mirror Polished
Key	Medical Syringe Mould
Size	According to Your Drawing
Name	Plastic Injection Mould
Transport Package	Wooden Package
Specification	steel
Trademark	Yongsheng
Origin	China Zhejiang Taizhou
HS Code	8480719090

Product Description

OEM Blood Test Tube disposable medical syringe barrel plunger mold with multiple cavities Hot runnerMOULD DESCRIPTION:

Cavity	1-72
Mould base material	P20 , 45# , 4CR13 , .ECT
Core&Cavity material	S136,718, P20,2378,2316,4CR13,P20 .ECT
Runner	Cold /Hot (LOCAL BRAND,HASCO,YUDO,HUSKY .ETC)
Life time	3,000,000 shots
Quick T1 time	25-40 days
Package	wooden case

Number of cavities: 6 cavities ~ 128 cavities
Cavity core steel: using StaVaxS420 manufactured by Assab, Sweden, it is a slider for stainless steel and tempered steel core: Luer interface slider system Injection gate type: hot runner point gate product plastic :PP
Syringe cavity core polishing: Mirror surface finish Syringe mold structure: It is mounted on the mold frame by inserting, and the same parts in the mold are interchangeable. Needle mold life: at least 5 million mold

Syringe size: 1~50 ml
The number of mold cavities can reach 16 cavity
Cavity core steel: manufactured by Assab, Sweden
StavaxS 420, which is stainless steel and tempered steel
Core slider: Luer interface slider system
Gate type: hot runner point gate
Product plastic: TPE or medical PVC (if using PVC, I
We do not recommend the use of thermal guides)
Cavity Core Polishing: Mirror Polishing
Needle plug plug mold structure: using the insert method to make it set
On the mold base, the same parts in the mold can be mutually
Changed.
Syringe tight plug die life: at least 5 million modeCavity core steel: using StaVaxS420 manufactured by Assab, Sweden, it is stainless steel and tempered steel gate type: hot runner point gate product plastic: PP or PE syringe piston cavity core polishing: Mirror-finished syringe cylinder mold structure: The insert method is used to insert it on the mold base, and the same parts in the mold can be interchanged.
Die life: at least 5 million modules

ADVANTAGE:1.Saving 10%-30% cost than others.2. Direct factory price3. Life:3, 000, 000 time4.2D and 3D provided5. Quick T1 time: 25-40 days6.More than 15 years experience PICTURE:

4.MOULD MANUFACTURE PROCESS:
Cap Mould : grinding→fly-cutter →CNC Milling→drilling→lathe→boring lathe→electric pulse →fine fly-cutter→polish→electroplate→install Preform Mould: grinding→drilling→lathe→boring lathe→fine fly-cutter→polish→electroplate→installNeed vale ,itself-locking :new advanced needle vale gate system.each cavity is self-lock independently to ensure low decent ration of product.The excellent hot runner design assures uniform heating and greatlyimproves the quality of plastic products
5.AFTER SALE SERVICE:
Any mould problem,we will provide free maintenance service

6. FLOW CHART

1	Sample or 2D,3D drawing from customer
2	Bulid 2D,3D drawing
3	CAD mould design
4	Send drawing to customer to confirm
5	Parts inspection/CNC machining/EDN machining
6	Mould assembly
7	Mould test
8	Send sample to confiom
9	Dilver the mould



Taizhou Huangyan Yongsheng Mould , founded in 2007, is located at Zhejiang province. It is near Hangzhou and Ningbo port. And domestic flights can arrive directly. You can go anywhere freely. Our company covers an area of more than 1, 000 meters. We are specializing in the development, production and sales of no gate hot runner cap mould, cut-free independent self-locking gate perform mould, free-gate valve perform mould, anti-theft cap mould, die cut cap mould, handle mould, bottles mould and daily necessities mould. Now we have had first-class experts and production machines.After many years of efforts and sustained fast developments, we have obtained customers' recognition with our scale, quality and good faith. Now we have got a clear advantage on technologies and equipments levels, quality grades, market share etc. And our core competencies are keeping on being stronger and stronger. It goes without saying that our company will develop steadily, rapidly and healthily. In order to be more professional, solider, stronger and bigger, we insist on perfect quality, good faith and customers first from our foundation, never stopped developing technologies and products.Now our products are popular in domestic market, and become a famous national brand. In oversea market, they are sold to Americas, Europe, Middle East, Africa and Southeast Asia. We will keep on fast development, strengthening personnel training and introduction, developing technologies, enhancing the capability of independent innovation, accelerating new plastic perform development, improving technology progress and industry upgrade, and carry out "going-out" strategy seriously, take part in the competition actively to open much wider market all over the world."YONGSHENG- keeps up with times and makes friends with all over the world"

Q:Could I have a sample to check the quality ?
A:Yes,for the ready in stock models, we could send out samples immediately, For out of stock models, we provide sampling service according to your requirement.
Q:How does your factory do regarding quality control?
A:Quality is priority! And all of raw material we used are environmental-friendly; Quality control department specially responsible for quality checking in each process.
Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefit ; We respect every customer as our friend and we sincerely do business and make friends with them.
Q:What's your payment term?
A:T/T, Paypal, Or Alibaba trade assurance.
Q:How much is the shipping cost?
A:It depends on the total weight of your order and the way you chose for shipping.There are International Express Door to Door,Airline Company and Ocean Transportation available.
Q:When is the delivery time?
A:According to your order quantity,the delivery time will be different. but all based on what materials what do you need.We will be very surportive in delivery if client has unchangeable promotion plan.
